AC Ratio Decade Transformers
AC Ratio Standard, 7 Decades
AC ratio decade transformers are critical tools for precise calibration and testing of electrical equipment. Engineered to provide accurate voltage and current ratios across a range of values, they offer unparalleled accuracy and linearity calibrating and verifying electrical parameters. With ratios selectable through rotary switches, they enable precise simulation of a large variety of values.
Eigenschaften
- Resolution 0.1 ppm
- Terminal linearity 0.9 ppm
- Bandwidth 50 Hz to 20 kHz
- Ratio range from -0.0111111 to +1.1111110
Vorteile
- Parallel switches reduce contact resistance
- Switch Resistors virtually eliminate switch transients
- 1 year warranty
- Assembled in USA
Spezifikationen
| Basic Accuracy/Linearity: | 0.00009% |
|---|---|
| Frequency Range: | 50 Hz to 20 kHz |
| Ratio Range: | -0.0111111 to +1.1111110 |
| Auflösung (°C): | 1 x 10⁻⁷ |
Technische Dokumentation
Verwandte Anwendungen
Alle Anwendungen erkunden
Dienstleistungen
Repair
Our worldwide service centers provide fast cycle times, use only AE-qualified parts, and follow the original product's specifications and test procedures for the highest quality repair or calibration.
| Product Family | Calibration | Calibration with Alignment |
Total Support Package (TSP) |
||||||
|---|---|---|---|---|---|---|---|---|---|
| Term of Agreement | Annual | One Year | Two Years | Three Years | Five Years | One Year | Two Years | Three Years | Five Years |
| TEGAM 5540 | | | | | | | | | |
| Lumasense | | | | | | | | ||
| Plasma Power | | | | | | | |||
Calibration and Alignment
Advanced Energy has the tools and processes to ensure your equipment continues to meet its original specifications. Our products are calibrated at global AE service sites with proprietary technology designed to exceed industry standards.
