DP100 (Level VI) Series

Active

100 W AC-DC Power Adapters

The new DP10054P3L is a 100 W freestanding external AC-DC power adapter that provides a very flexible Power over Ethernet (POE) compliant power solution for a wide variety of portable and desktop applications. The adapter accepts a wide 90 to 264 VAC input and provides a single, fully regulated 54 VDC output that is capable of delivering up to 1.85 A continuously. DP100 series adapters have a typical full load efficiency of 87% and comply with DoE Level VI and EU CoC v5 Tier 2 efficiency requirements.

Features

Built in EMI filter (CISPR 22 class B)
Efficiency complies with European CoC v.5 Tier 2 & US DoE Level VI
Fully regulated 54 V output
IEC320 AC input receptacle, 3 pin (Type C6)

Benefits

AC input fuse
Active PFC
High efficiency
High MTBF
Overcurrent, overvoltage and thermal protections
POE isolation on the output
Universal AC input

Specifications

Output Power (W):	100
Length (Inches):	6.14
Width (Inches):	2.56
Height (Inches):	1.46
Mounting Type:	External Adapter
Minimum Output Current (A):	0
Maximum Output Current (A):	1.85
Output Voltage Range (V):	54V to 54V
Minimum Output Power (W):	0
Maximum Output Power (W):	100
Minimum Input Voltage (V):	90
Maximum Input Voltage (V):	264
Warranty (Years):	2

All Specifications Collapse Specifications

Stock Check

Model Number Samples Buy	Min. Voltage (V)	Max. Voltage (V)	Current (A)	Nominal Voltage (V)	Number of Outputs	Samples	Buy
DP10054P3L Active, In Stock Request Buy	54	54	1.85	54	1	Request	Buy

Technical Documentation

Title	Type
DP100 DS Datasheet (265 KB)	Data Sheet
RoHS2 CoC DP10054P3L RoHS Certificate (95 KB)	RoHS Certificate
DP100 (Level VI)—DP10054P3L CB Certificate (242 KB)	Safety Certificate
DP100 (Level VI)—DP10054P3L CCC (846 KB)	Safety Certificate
DP100 (Level VI)—DP10054P3L Declaration of Conformity (194 KB)	Safety Certificate
DP100 (Level VI)—DP10054P3L PSE (2 MB)	Safety Certificate
DP100 (Level VI)—DP10054P3L TUV (312 KB)	Safety Certificate
DP100 (Level VI)—DP10054P3L UL (162 KB)	Safety Certificate
