SL Power™
GE30D Series
Active
24 W Dual Output External Power Adapters
Advanced Energy’s SL Power GE30D series of desktop AT A GLANCE AC-DC external power adapters provide up to 24 W dual output power with IP20 rated enclosure. GE30D series power adapters meet industrial & medical safety approvals and accept a universal input of 90 to 264 VAC. These power adapters feature output overvoltage, overtemperature, overload and short-circuit protections.
Features
- Up to 24 W of AC-DC Power
- Universal Input 90 to 264 VAC Input Range
- >250,000 hours MTBF
Benefits
- Dual Output - Main + USB Port
- USB A port for auxiliary power
- Approved to EN/IEC/UL60601-1, 3rd edition and IEC62368-1
- 2 MOPP output-output isolation. 1 MOPP input-output isolation
- Meets EN55011/CISPR11, FCC Part 15.109
- Class B Conducted & Radiated Emissions
- IP20 Rated Enclosure
- 3 Year Warranty
Specifications
| Output Power (W): | 24 |
|---|---|
| Length (Inches): | 6 |
| Width (Inches): | 4 |
| Height (Inches): | 1.6 |
| Mounting Type: | External Adapter |
| Minimum Output Current (A): | 2.4 |
| Maximum Output Current (A): | 2.4 |
| Output Voltage Range (V): | 5V to 5V |
