artesyn™
LPS60 Series
Active
60 to 80 W AC-DC Power Supplies
The LPS60 series of open-frame AC-DC power supplies comprises six single output models, offering voltages of 3.3 V, 5 V, 12 V, 15 V, 24 V or 48 V. Each model accepts a universal input of 85 to 264 VAC or 120 to 300 VDC. These compact switch-mode power supplies feature output overvoltage and short-circuit protection, as well as remote sense. LPS60 series power supplies provide 60 W of output power with free air convection cooling and 80 W with 30 CFM of forced air. They are suitable for a wide variety of applications, including test and measurement, single-board computers, telecommunications and networking.
Features
- 3" x 5" footprint
- LPX60 enclosure kit available
- Safety ground leakage current < 0.5 mA @ 50/60 Hz, 264 Vac input
- Efficiency 70% typical at full load
- Input range 85 - 264 Vac, 120 - 300 Vdc
- Inrush current <18 A peak @ 115 Vac ; < 36 A peak @ 230 Vac
- EMI filter FCC Class B conducted CISPR 22 Class B conducted
- Frequency 47 - 440 Hz
- Input current 1.5 A max. (RMS) @ 115 Vac
- Adjustment range -5, +10% minimum
- Remote sense Compensates for 0.5 V lead drop min.
- Hold-up time 20 ms @ 60 W load, 115 Vac nominal line
- Maximum power 60 W for convection; 80 W with 30 CFM forced air
- Overvoltage protection 5 V output: 5.7 -6.7 Vdc. Other outputs 10% to 25%
Benefits
- Adjustable output voltage
- Built-in EMI filter
- Low output ripple
- Overload protection
- Overvoltage protection
- Remote sense
- RoHS compliant
- Universal input
- Overload protection Short circuit protection on all outputs.
Specifications
| Output Power (W): | 80 |
|---|---|
| Length (Inches): | 5 |
| Width (Inches): | 3 |
| Height (Inches): | 1.65 |
| Mounting Type: | Embedded PSU |
| Minimum Output Current (A): | 1.3 |
| Maximum Output Current (A): | 16 |
| Output Voltage Range (V): | 3.135V to 52.8V |
