artesyn™
iLS600 Series
Active
Intelligent Laboratory Power 600 W Bench Programmable Power Supplies
Advanced Energy’s Artesyn iLS600 series are programmable DC power supplies with a single output that offers output power to 600 W. With 12-bit D/A & A/D converters embedded, the power supplies come with the capability of reporting voltage and current very accurately. The iLS600 series provide convenient digital rotary controls for voltage and current adjustment and the power supplies come with front ports that allow remote control via USB, Ethernet, and analog control inputs. iLS600 series are LXI certified, details for using this interface can be found in our Programming Manual.
Features
- 5 models: up to 400V and 33A
- 600W with extended range
- Small, highdensity 1U package
- Input Voltage 100 - 240 Vac
- #of Outputs 1
- Total Power 600 Watts
- Output Voltage 30 - 400 V
- Output Current 2.5- 33 A
- RMS Constant Voltage 20 - 150 mV
- P - P Constant Voltage 60 - 200 mV
- Load: 10-90% - Voltage 15 - 200 mV
- Load: 10-90% - Current 15 mV
- Line: 180-260 VAC Input2,3 - Voltage 15 - 200 mV
- Line: 180-260 VAC Input2,3 - Current 15 mV
- Weight 6 lbs. (2.7 Kg)
Benefits
- Built-in voltage and current measurement
- Full OCP and OVP protection
- LXI certified
- Series and parallel operation
- Wireless digital remote sense
Specifications
| Output Power (W): | 600 |
|---|---|
| Length (Inches): | 10.3 |
| Width (Inches): | 8.82 |
| Height (Inches): | 1.73 |
| Mounting Type: | Rack-mount |
| Minimum Output Current (A): | 2.5 |
| Maximum Output Current (A): | 33 |
| Output Voltage Range (V): | 30V to 400V |
Accessories
Technical Documentation
Technical Videos
Intelligent Programmable DC Power Supplies - Advanced Energy’s Artesyn iLS Series
Jul 19, 2021
Advanced Energy’s Artesyn iLS series of intelligent programmable DC power supplies provide an ultra-accurate source and precise measurement of voltage and current for laboratory, test and measurement, automated test equipment, and research and development applications.
