NeoPower™ NP05 Series

Active

AC-DC PSU | Configurable & Efficient

在庫チェック営業担当データシート

The NeoPower NP05 AC-DC configurable power supply introduces best-in-class power density of 17 W/in³. For up to 2400 W output power, NP05 is easy to configure (series or parallel) and has five output power slots. NP05 can drop into an OEM’s enclosure to make a custom power supply or simply be used for its high flexibility for any embedded or power conversion challenge requiring multiple outputs.

特徴

High power density
Multiple digital communication protocol options via adapters: MODBUS RTU, MODBUS TCP, CANBUS, and PMBUS
Programmable as a voltage or a current source.
Market-leading low ripple noise
User-configurable
Medical IEC/EN 60601-1 3.2 Compliant and BF Rated
Semi F47
Simplified buss bar design

メリット

More power in 2.5" configurable compared to the competition
Operate in constant voltage or constant current mode
Flexible communications
Fast deployment
Higher power signal and accuracy
Easy-to-configure modules
Certified industrial and medical applications
Configurable buss bars for any series/parallel combination
Confidence in reliability from the #1 configurable power supply manufacturer

仕様

出力電力 (W):	2400
長さ（インチ）:	11.2
幅（インチ）:	8
高さ（インチ）:	2.5
マウントタイプ:	Various
最小出力電流 (A):	0
最大出力電流 (A):	280
出力電圧範囲 (V):	300
最小出力（W）:	0
最大出力（W）:	2400
Minimum Input Voltage (V):	90
最大入力電圧 (V):	264
保証期間（年）:	5

すべての仕様仕様の崩壊

在庫チェック

* デモあり。

モデル番号サンプル購入	効率(%)	最小電圧 (V)	最大最大電圧 (V)	電流 (A)	公称電圧 (V)	出力数	サンプル	購入
83-011-0005L* Active, お問い合わせ NeoPower 1 slot, 1 output 5V nominal module Features low differential and common mode ripple お問い合わせ購入		1	6	56	5	1	お問い合わせ	購入
83-011-0005M* アクティブ, 在庫あり NeoPower 1 slot, 1 output 5V nominal module Request 購入		1	6	56	5	1	Request	購入
83-011-0012L* Active, お問い合わせ NeoPower 1 slot, 12V output V nominal module Features low differential and common mode ripple お問い合わせ購入		2.4	14.4	41.6	12	1	お問い合わせ	購入
83-011-0012M* アクティブ, 在庫あり NeoPower 1 slot, 1 output 12V nominal module Request 購入		2.4	14.4	41.6	12	1	Request	購入
83-011-0015L* Active, お問い合わせ NeoPower 1 slot, 1 output 15V nominal module Features low differential and common mode ripple お問い合わせ購入		3	18	33.3	15	1	お問い合わせ	購入
83-011-0015M* アクティブ, 在庫あり NeoPower 1 slot, 1 output 15V nominal module Request 購入		3	18	33.3	15	1	Request	購入
83-011-0024L* Active, お問い合わせ NeoPower 1 slot, 1 output 24V nominal module Features low differential and common mode ripple お問い合わせ購入		4.8	28.8	20.8	24	1	お問い合わせ	購入
83-011-0024M* アクティブ, 在庫あり NeoPower 1 slot, 1 output 24V nominal module Request 購入		4.8	28.8	20.8	24	1	Request	購入
83-011-0048L* Active, お問い合わせ NeoPower 1 slot, 1 output 48V nominal module Features low differential and common mode ripple お問い合わせ購入		9.6	57.6	10.4	48	1	お問い合わせ	購入
83-011-0048M* アクティブ, 在庫あり NeoPower 1 slot, 1 output 48V nominal module Request 購入		9.6	57.6	10.4	48	1	Request	購入
83-105-0001W* Active, お問い合わせ NeoPower 5-slot Case Up to 5 isolated outputs 1VDC - 300VDC output お問い合わせ購入	90						お問い合わせ	購入

アクセサリー

PowerPro CANBUS/PMBUS Dongle

Add CANBUS and PMBUS capability

View Page

技術文書

Product Information Documents Updated

Insights & Studies

Miscellaneous

ソフトウェア

NeoPower Configurable Software

View Page

テクニカル・ビデオ

New NeoPower™ NP05 Configurable AC-DC Power Supplies

2月 6, 2025

New NeoPower(TM) NP05 Configurable AC-DC Power Supplies Advanced Energy has expanded our NeoPower™ family of ultra-high-density configurable AC-DC power supplies with the 5-slot NP05, which offers 2.4 kW in an industry-standard 2.5-inch form factor. We also offer two new low-noise modules and a PowerPro(TM) Ethernet adapter. These innovative options save space and reduce electrical noise, while the adapter simplifies Ethernet connectivity. This makes these solutions ideal for advanced industrial, medical, and test applications.
