tegam ®
ST-200A AC Ratio Transformer
Active
AC Ratio Standard, 1:1 Ratio, Binding Post Termination, Center-Tapped Secondary (not CE certified)
Advanced Energy's TEGAM ST-200A transformers are designed to meet the requirements of a wide variety of bridge circuitry, isolation and calibration applications. The ST-200A can be used to provide a balanced output from an unbalanced source. These transformers may be combined with TEGAM ratio transformers in bridging circuits, to isolate the null indicator. The ST-200A features very accurate 1:1 ratio for isolation or phase inverting applications. Units are also used with TEGAM Ratio Transformers to provide 180 degree phase shift to the input or output of the instrument in certain bridge applications. The ST-200A also has a center-tapped secondary.
특징
- 1:1 Turns Ratio
- Frequency Range 50-10,000 Hz
- Insulation 500-V Test
- Open Circuit Ratio Accuracy at 400 Hz .005%
- Input Impedence (with secondary open circuit) at 400 Hz, Greater than 250,000 ohms
- Binding Post Termination
- Center-tapped Secondary
- NSN: 5959-00-715-8591
- Assembled in USA
혜택
- Excellent for isolation applications
사양
| Basic Accuracy/Linearity: | 0.005% |
|---|---|
| Frequency Range: | 50 Hz to 10 kHz |
| Ratio Range: | 1:1, 1:0.5 |
| 해상도(°C): | N/A |
