SIL20C2 Series

Active

100 W (20 A) Non-Isolated DC-DC Converters

The SIL20C2 series 20 A high density non-isolated DC-DC converter is designed for cost- and space-sensitive applications. It accepts a wide range 4.5 to 13.8 VDC input and provides an output that is adjustable from 0.59 to 5.1 VDC to accommodate a wide variety of silicon power needs. Rated at 100 W, the converter has a typical efficiency of 93%. Standard features include remote sense, remote On/Off and remote ‘power good’ indication. SIL20C series converters offer a choice of through-hole horizontal and through-hole vertical mounting.

特点规格库存检查技术文档 Support

特点

High Efficiency up to 93%
Wide input voltage range: 4.5 to 13.8Vdc
Wide output voltage trim / adjustability: 0.59 to 5.1Vdc
Input Range 4.5 to 13.8 VDC
Wide Output Trim 0.59 to 5.1 VDC

益处

Current sink capability for termination applications
Excellent transient response
No added input or output capacitors needed for ripple capability or stability
Remote on/off
Remote sense

规格

输出功率（瓦）:	100
长度（英寸）:	1.2
宽度（英寸）:	0.61
高度（英寸）:	0.482
安装类型:	BMP; Through Hole
最小输出电流 (A):	20
最大输出电流 (A):	20
输出电压范围 (V):	0.59V to 5.1V
最小输出功率（瓦）:	100
最大输出功率（瓦）:	100
Minimum Input Voltage (V):	4.5
最大输入电压 (V):	13.8
保修期（年）:	2

所有规格折叠规格

库存检查

型号样品购买	最小值电压 (V)	最大电压电压 (V)	电流 (A)	标称电压 (V)	输出数量	样品	购买
SIL20C2-00SADJ-HJ 活动，有库存要求购买	0.59	5.1	20	0	1	要求	购买
SIL20C2-00SADJ-VJ 活动，有库存要求购买	0.59	5.1	20	0	1	要求	购买

技术文档

标题	类型
SIL20C2—Application Note (3 MB)	应用说明
SIL/SMT20C2 Series Data sheet (565 KB)	数据表
SIL20C2—Certificate of RoHS Compliance (40 KB)	RoHS 证书
CB Report (336 KB)	安全证书
SIL_SMT_LDO_70012XX_TUV Certificate (EN 62368-1) (1 MB)	安全证书
TUV (155 KB)	安全证书
UL Safety Certificate (60 KB)	安全证书
SIL20C2—Longform Datasheet (3 MB)	技术参考
