Artesyn™
AVE700 Series
Active
700 W 1/2 Brick
Advanced Energy’s AVE700-48S28 series offers single output DC-DC converters with standard half-brick outline and pin configuration. Delivering up to 25 A output current with 28 V output, these converters provide ultra-high 95.5% efficiency and excellent thermal performance. Ideal for computing and telecommunication applications, the AVE700-48S28 series operates over an ambient temperature range of -40˚C to +85˚C without air cooling, and baseplate operating temperature up to 100˚C. Trim the output voltage from 14 to 33 VDC (AVE700-48S28) to meet a broad range of applications needs with no minimum load requirement.
特点
- 36 65 Vdc Telecom input range
- 700 W continuous power
- RoHS 6 compliant
- Trim function: 50% ~118%
- UL94 V0 materials
- Ultrahigh efficiency 95% @ 100% load
- Input voltage 36V - 75 Vdc
- Output voltage 28 Volts
- Output current 25 Amps
- Isolation 1500 Vdc
- Mechanical outline standard 1/2 brick
益处
- Contact cooling or heatsink mounting
- Excellent thermal performance
- Fixed switching frequency
- Fully regulated output voltage
- High reliability
- Industry standard halfbrick
- Low ripple and noise
- No minimum load requirement
- Output overcurrent protection
- Output overvoltage protection
- Output shortcircuit protection
- Overtemperature protection
- Remote control function
- Remote output sense
- Logic control - analogue Positive or Negative enable
- Basic insulation
规格
| 输出功率（瓦）: | 700 |
|---|---|
| 长度（英寸）: | 2.4 |
| 宽度（英寸）: | 2.3 |
| 高度（英寸）: | 0.5 |
| 安装类型: | BMP; Through Hole |
| 最小输出电流 (A): | 0 |
| 最大输出电流 (A): | 25 |
| 输出电压范围 (V): | 14V to 33V |
